The AL-1600E lifts its 6-section mast electrically and rotates 359° to place light exactly where the crew is working. An IP65 rating keeps the electrics alive in driving rain and dust.
AL-1600E Full Unit Overview
Lamp Head & MastControl Panel
KEY FEATURES
Push-Button Mast
Electric lifting – no cranking, no hydraulics to service.
359° Self-Locking Rotation
Swing the light head to the work area and it stays put.
4×400 W LED Lighting
360,000 lm with long service life and low power draw.
Sealed electrics keep working in driving rain and dust.
Five Windproof Support Legs
Rated for 20 m/s wind, fully deployed.
60 Hours Per Fill
The 100 L tank sees you through the longest night shifts.
LIGHT SOURCE
Lamp Configuration
4 x 400 W LED
Luminous Flux
360,000 lm
DIESEL ENGINE OPTIONS
Engine Brand
Engine Model
Cylinders
Power
Kubota
Z482
2
4.5 kW
Yanmar
D1105
3
12.6 kW
Kohler
3TNV76
Water-cooled 4-stroke
11.1 kW
GENERATOR & ELECTRICAL
Frequency / Speed
1800 rpm
Rated Voltage
240 V
Alternator
Brushless, standard fit
Insulation Class
Class H
Protection Rating
IP65
Continuous Working
60 hours
Fuel Tank Volume
100 L
Start-up Method
Key start
MAST & LIFTING SYSTEM
Mast Sections
6-section
Lifting Mode
Electric
Mast Rotation
359° max manual rotation, self-locking
Max Lifting Height
9 m
Wind Resistance
20 m/s
Noise Level
72 dB(A) at 7 m
TRAILER & DIMENSIONS
Suspension & Brakes
Leaf spring suspension & single axle without brakes
Towbar
With retractable guide wheel adjustment lever
Overall Length
2,450 mm
Overall Width
1,350 mm
Overall Height
2,650 mm
Tire & Rim Size
14 inch
TYPICAL APPLICATIONS
Where This Tower Works
Urban night construction, municipal maintenance, events and exhibitions, parking areas – sites where the tower is repositioned often and space is tight.
Manual/Autostart Optional, Brand: Deep Sea, SmartGen, ComAp
Construction
Highly Corrosion Resistant Construction with Shock Absorbers
Enclosure Features
Weatherproof & Soundproof Canopy with Integrated Fuel Tank & Exhaust Silencer
