ALM22000 Premium 20kW Methanol Generator Set | Clean Energy Backup Power

Product name:	20kW Methanol Generator Set
Model Number:	ALM22000
Certification:	ISO9001:2008, CE
Alternator:	Stamford, Leroy Somer, Marathon etc.
Rated Voltage:	230/400V
Rated RPM:	3000rpm
Frequency:	50Hz or 60Hz
Minimum Order Quantity:	1 set
Packaging Details:	Wooden package
Delivery Time:	within 15 days
Payment Terms:	T/T, L/C, Western Union, MoneyGram
Shipping Method:	Door-to-Door, Sea Freight

Inquiry Now

20kW Eco-Friendly Methanol Generator Set

Stable and Economical Power Support for Various Small to Medium-Sized Scenarios

Working Principle

A methanol generator set is an innovative green device that efficiently converts the chemical energy of methanol into electrical energy. It utilizes an advanced internal combustion engine core to burn premium methanol fuel to generate high-temperature thermal energy. This thermal energy precisely drives a heavy-duty piston system, transforming heat into robust mechanical force, which is then seamlessly converted into reliable electricity by a high-performance alternator. Within the internal combustion engine, methanol is perfectly atomized and mixed with air, then ignited via a precision electronic ignition system to ensure continuous, clean, and sustainable power output.

Key Features & Highlights

The 20kW methanol generator set stands out as a highly “flexible and premium choice” for small to medium-sized power consumption scenarios. It is engineered specifically to meet the rigorous demands of small homestays, community service stations, and temporary outdoor work sites.

Compact Design & Versatile Application

High Portability: Designed with a compact structure that offers superior mobility and swift deployment across different temporary work sites without complex setups.
Heavy-Load Support: Stably drives essential daily appliances (refrigerators, high-intensity lighting, small water pumps) while effortlessly powering small manual processing equipment.
Industrial-Grade Reliability: Core components have passed multiple rounds of intensive reliability testing, ensuring an ultra-fast startup response and an exceptionally low failure rate.

Energy-Saving & Whisper-Quiet Operation

Optimized Fuel Consumption: Equipped with an advanced energy-saving methanol combustion system that dramatically increases fuel utilization and lowers daily running costs.
Eco-Friendly Emissions: Fully complies with international civil environmental standards, operating cleanly with significantly minimized carbon footprint.
Silent Operation Technology: Combined with an acoustic-optimized enclosure and internal dampening, it guarantees minimal sound interference to the surrounding environment during daily use.

Technical Specifications & Parameters

*Note: The parameters listed below represent the standard structural and electrical configurations for this premium 20kW open-type methanol genset unit.

Parameter	Unit	Specification
Rated Frequency	Hz	50
Rated Voltage	V	230/400
Rated Power	kW	20
Rated Current	A	28.8
Rated Speed	rpm	3000
Alternator System	—	Self-Excited Features
Pole NO.	—	2
Phase NO.	—	three phase
Excitation way	—	Self excited constant voltage
Power factor	cos Φ	0.8(lag)
Insulation class	—	F
Engine System	—	Liquid-Cooled Core
Cylinder type	—	4-cylinder, 4-stroke, liquid-cooled, 8-Valve
Fuel injection system	—	Electronic injection system
Displacement	L	1.05
Lubrication way	—	Pressure
Lubricating Oil	—	Methanol engine oil
Lubricating Oil capacity	L	3.5
Fuel Type	—	Methanol M100
Genset Assembly	—	Structure & Dimensions
Start way	—	Electric start
Start motor	V – kW	12V/0.8kW
Battery capacity	V – Ah	12V60Ah
Generator Set type	—	Open type
Output Type	—	Leakage protector
Fuel capacity	L	76
External dimensions	mm	1200×800×1060
Weight	kg	295
